| Min. Order: | 1 Set/Sets |
|---|---|
| Trade Term: | FOB |
| Payment Terms: | Paypal, L/C, T/T |
| Place of Origin: | Anhui, China (Mainland) |
| Means of Transport: | Ocean, Land |
| Delivery Date: | within 30 days after... |
| Brand Name: | HEKING |
| Weight: | 8.2ton | Max.digging reach: | 6.7m |
|---|---|---|---|
| Standard bucket capacity: | 0.4m³ | Overall length: | 6.7m |
| Overall width: | 2.15m | Overall height: | 2.64m |
| Engine: | Yanmar 4TNV98T | Pump: | Toshiba PVC90RC06 |
| Valve: | Toshiba IB18-8021 | Swing motor: | Toshiba SG025E-136 |
8.2 Ton HEKING HK85 Crawler Excavator with Yanmar & Toshiba Hydraulics
Yanmar turbo engine delivers strong torque and fuel efficiency
Toshiba hydraulic system ensures smooth and precise control
0.4m³ bucket improves loading and excavation productivity
28MPa working pressure for stable heavy-duty performance
35° gradeability for uneven terrain operations
Large 300L fuel tank for extended working hours
Reinforced chassis with 112.2kN tractive effort
Optimized transport dimensions for container shipping
Suitable for contractors, dealers, and rental fleets
The HEKING HK85 Crawler Excavator is an advanced 8.2-ton class machine engineered for contractors and heavy equipment distributors across Europe and the Middle East. Positioned within the competitive crawler excavators segment, the HK85 combines high-output engine power, robust hydraulic technology, and optimized structural design to meet the performance standards required in modern construction, municipal engineering, and infrastructure projects.
The HK85 is powered by the Yanmar 4TNV98T inter-cooled turbo diesel engine, delivering 54.3kW at 2200rpm and maximum torque of 310N·m at 1600rpm. This 4-cylinder, 3.319L engine is widely recognized in export markets for reliability, fuel economy, and low maintenance costs.
For wholesale buyers, this means stable performance under continuous workloads, simplified spare parts supply, and long-term operational durability—essential for rental fleets and government infrastructure contractors.
Certifications
The hydraulic system is equipped with a Toshiba PVC90RC06 variable plunger pump and Toshiba IB18-8021 valve assembly. Operating at 28MPa working pressure, the system ensures responsive control, strong digging force, and consistent oil flow distribution.
The Toshiba SG025E-136 swing motor and Jeil JMV-53/31-01/VBC-RJ-47 travel motor provide reliable rotation and travel stability, ensuring balanced operation on complex job sites. This configuration enhances machine precision during trenching, grading, lifting, and foundation excavation.
With a standard 0.4m³ bucket capacity and maximum digging reach of 6695mm, the HK85 delivers high productivity in urban construction and mid-scale earthmoving operations.
Key working performance includes:
Maximum digging depth: 4193mm
Maximum digging height: 6323mm
Maximum dumping height: 4391mm
Bucket digging force: 49kN
Arm digging force: 43.4kN
These specifications make the HK85 suitable for road construction, pipeline installation, building foundations, landscaping, and agricultural development projects.
Weighing 8220kg, the HK85 features a reinforced undercarriage with 450mm track shoes and a 1700mm track gauge for improved stability. Ground pressure of 0.13kg/cm² allows efficient operation on soft ground conditions.
Transport dimensions (6664mm length × 2150mm width × 2644mm height) support efficient container loading and sea freight to European and Middle Eastern ports. The compact structure ensures accessibility in confined job sites while maintaining powerful performance.
The HK85 is developed specifically for international wholesale buyers:
Production time: Within 30 days after down payment
Payment terms: T/T 30% deposit, 70% before delivery
This structured production cycle ensures supply chain planning flexibility for distributors and contractors managing project deadlines.
Overall, the HEKING HK85 Crawler Excavator delivers balanced power, hydraulic precision, and procurement efficiency. It is an ideal solution for professional contractors and equipment dealers seeking reliable crawler excavators in the 8-ton segment.
Specification
| Weight | 8220KG | ||||
| Standard bucket capacity | 0.4m³ | ||||
| Boom length | 3500mm | ||||
| Arm length | 1700mm | ||||
| Chains | 2 | ||||
| Engine model | Yammar 4TNV98T | ||||
| Type | inter-cooled turbo | ||||
| Power | 54.3kW/2200rpm | ||||
| Max.torque | 310N m / 1600rpm | ||||
| No.of cylindar | 4 | ||||
| Displacement | 3.319L | ||||
| Type | Variable plunger pump | ||||
| Max.displacement | 2250px3/r | ||||
| Working pressure | 28Mpa | ||||
| Slew motor | fixed plunger | ||||
| Travel motor | variable plunger | ||||
| Slew speed | 12rpm | ||||
| Min.slew radius | 2257mm | ||||
| Max.travel speed high/low | 3.79km/h | ||||
| Gradeability | 35° | ||||
| Tracktive effort | 112.2kN | ||||
| Max.digging force of bucket | 49kN | ||||
| Max.digging force of arm | 43.4kN | ||||
| Ground pressure | 0.13kg/cm2 | ||||
| Fuel tank capacity | 300L | ||||
| Hydraulic tank capacity | 140L | ||||
| Item | Standard(mm) | ||||
| Wheel span | 2261 | ||||
| Length of track | 2907 | ||||
| Gound clearance of platform | 831 | ||||
| Overal length | 6664 | ||||
| Transportating height | 2644 | ||||
| Rear slew radius | 2106 | ||||
| Track gauge | 1700 | ||||
| Max.width | 2150 | ||||
| Track shoe width | 450 | ||||
| Min.ground clearance | 373 | ||||
| Height of track | 706 | ||||
| Max.width of upper structure | 2200 | ||||
| Item | Standard(mm) | ||||
| Max.digging reach | 6695 | ||||
| Max.digging reach on ground | 6557 | ||||
| Max.digging depth | 4193 | ||||
| Max.vertical digging depth | 3098 | ||||
| Max.digging height | 6323 | ||||
| Max.dumping height | 4391 | ||||
| Min.front slewing radius | 2621 | ||||
| Engine | Yanmar 4TNV98T | ||
| Pump | Toshiba PVC90RC06 | ||
| Valve | Toshiba IB18-8021 | ||
| Swing motor | Toshiba SG025E-136 | ||
| Travel motor | Jeil JMV-53/31-01/VBC-RJ-47 | ||
Q1: Is the HK85 suitable for large-scale construction projects?
A: Yes. With 49kN bucket digging force and 28MPa hydraulic pressure, it is suitable for mid-scale earthmoving and infrastructure work.
Q2: What makes the hydraulic system reliable?
A: The machine uses Toshiba variable plunger pump and valve systems, ensuring smooth operation and stable oil flow control.
Q3: How long is the production lead time?
A: Production is completed within 30 days after receiving the 30% down payment.
Q4: Can the HK85 be used for rental fleets?
A: Yes. Its durable engine, strong structure, and fuel efficiency make it ideal for rental companies.
Q5: Is spare parts availability guaranteed in Europe and the Middle East?
A: Yanmar and Toshiba components are widely supported internationally, simplifying spare parts sourcing.
Q6: What terrain can this crawler excavator handle?
A: With 35° gradeability and strong tractive effort, it performs well on uneven and sloped terrain.
Q7: Can you provide OEM branding support?
A: Yes. HEKING supports OEM/ODM customization for distributors.
